P235GH Seamless Steel Pipe
P235GH is a normalized carbon low alloy steel specified in European standards EN 10216-2 and EN 10028-2. It features good plasticity, toughness, cold bending, and welding properties, making it ideal for elevated working temperatures. The 'P' denotes weldable, 'G' softened annealed, and 'H' hardened. It is widely used in the manufacturing of boilers, heat exchangers, and pressure vessels in the oil, gas, and petrochemical sectors.
EN: P235GHDIN: 17175 St45.4 (Superseded)BS: 1501-161-360A (Superseded)
MaterialEN 10216-2 / EN 10028-2
Thickness1-30 mm
WidthN/A (Pipe OD)
LengthMax 12000 mm
MOQ1 Ton
Lead Time7-15 days
PortShanghai / Tianjin
Response within 24 hours
In Stock — Ready to Ship
| Material Grade | EN 10216-2 / EN 10028-2 | Standard | EN 10216-2 / EN 10028-2 |
| Thickness Range | 1-30 mm | Width Range | N/A (Pipe OD) |
| Length Range | Max 12000 mm | MOQ | 1 Ton |
| Lead Time | 7-15 days | Port of Shipment | Shanghai / Tianjin |
| C | ≤0.16 | Si | ≤0.35 |
| Mn | 0.60-1.20 | P | ≤0.025 |
| S | ≤0.010 | Cr | ≤0.30 |
| Cu | ≤0.30 | Ni | ≤0.30 |
| Mo | ≤0.08 | Tensile Strength | 350-480 MPa |
| Yield Strength | ≥185 MPa | Elongation | ≥24% |
